NM400 Wear Plate Supplier | NM450 / NM500 Abrasion Resistant Steel Plates

Introduction

NM400 wear plate is the most widely used abrasion resistant steel plate for mining, construction, and material handling equipment. Designed through quenched and tempered processing, NM400 steel plate provides a reliable balance between wear resistance, toughness, and fabrication performance.

As an experienced exporter, CJM supplies NM400 wear plates in stable stock with standard thickness ranges, fast delivery, and cut-to-size processing. For applications requiring higher hardness and longer service life, NM450 and NM500 wear plates are also available.

NM400 / NM450 / NM500 Wear Plates Product Parameters

Product Type	Wear-Resistant Steel Plates
Grades	NM400 / NM450 / NM500
Thickness	2-100mm or Customer’s request
Width	1000-3000mm / 1250mm / 1500mm / 2000mm / customized
Length	2000–12000 mm or as required
Application	Mining equipment, construction machinery, crushers, hoppers, truck bodies
Surface Condition	Black surface or shot-blasted
Delivery Condition	Quenched and Tempered (Q&T)
Packing	Strong sea-worthy package
Supply Capability	Plates, cut-to-size parts, OEM processing
Standard stock	Common thicknesses available
MOQ	Flexible, suitable for both project and wholesale orders

For ASTM-grade alternatives, see AR400 / AR450 / AR500 Abrasion Resistant Steel Plate.

NM400 Wear Plate (Main Grade for Most Applications)

NM400 wear plate is the most commonly selected grade in the NM series due to its balanced performance and cost efficiency.

It is widely used for:

• Excavator buckets
• Dump truck bodies
• Wear liners and chutes
• General abrasion-resistant structures

Compared with higher hardness grades, NM400 steel plate offers better cutting, welding, and forming performance, making it suitable for fabricated wear parts.

NM450 and NM500 Wear Plates for Higher Wear Resistance

For more demanding working conditions, NM450 and NM500 wear plates provide increased hardness and longer service life.

• NM450 wear plate: Suitable for medium to heavy abrasion environments where longer lifespan is required
• NM500 wear plate: Designed for severe wear conditions such as crushers, mining equipment, and high-impact zones

Using NM500 steel plate can reduce plate thickness while maintaining durability, helping improve payload efficiency.

Chemical Composition of NM400 / NM450 / NM500 Wear Plates

Below are the detailed chemical compositions of NM400, NM450, and NM500 steel plates, ensuring consistent quality and traceability for buyers.

Grade	c	Si	Mn	P	S	Al	Cr+Ni+Mo	Nb+V+Ti
NM400	0.10-0.40	0.20-0.40	1.00-2.00	Max 0.015	Max 0.003	Min 0.020	Max 0.9	Trace Amount
NM450	0.10-0.40	0.20-0.40	1.00-2.00	Max 0.015	Max 0.003	Min 0.020	Max 1.2
NM500	0.10-0.40	0.20-0.45	1.00-2.00	Max 0.015	Max 0.003	Min 0.020	Max 1.5

Mechanical Properties of NM Series Wear Plates

CJM assists buyers in selecting the most cost-effective grade based on working conditions, wear intensity, and fabrication requirements.

• NM400 wear plate is recommended for applications requiring good abrasion resistance with easier cutting and forming, such as buckets, liners, and general wear parts.
• NM450 wear plate offers a balance between hardness and service life, suitable for medium to heavy abrasion environments.
• NM500 wear plate is designed for severe wear conditions where maximum hardness and extended service life are required, such as crusher liners and dump truck bodies.

For applications requiring even higher hardness levels, please refer to NM550/NM600 Steel Plate product page.

The following mechanical properties explain why NM400, NM450, and NM500 wear plates are widely selected for high-wear environments.

Grade	Size(mm)	RP0.2(Mpa)	Rm(Mpa)	A50(%)	AKV,(ºC)	KV2(J)			HBW
NM400	100	1233	1337	15	-20	35	37	42	415
NM450	60	1345	1434	9.5	-20	72	59	58	455
NM500	50	1608	1706	10.5	-20	43	50	45	495

NM400 vs NM500 Wear Plate: How to Choose

Choosing between NM400 and NM500 wear plates depends on wear intensity, fabrication requirements, and cost considerations.

• Select NM400 wear plate for general wear parts requiring easier processing and lower cost
• Select NM500 wear plate for maximum wear resistance and longer replacement cycles
• NM450 serves as a balanced option between performance and cost

For most projects, NM400 provides sufficient performance, while NM500 is preferred in high-abrasion environments.

NM400 Wear Plate Supplier with Stock and Processing Service

CJM supplies NM400 wear plates for global projects with stable inventory and flexible processing capabilities.

Our supply advantages include:

• Stock Availability: Common thicknesses available for fast shipment
• Cut-to-Size Service: CNC cutting based on drawings
• Flexible MOQ: Suitable for both wholesale and project orders
• Export Support: Full documentation including MTC, SGS, BV
• Global Delivery: Stable shipping to Asia, Middle East, Africa, Europe, and Americas

We focus on providing reliable NM400 steel plate supply for long-term project cooperation.

Applications of NM400 / NM500 Wear Plates

NM-series wear plates are widely used in industries where abrasion resistance is critical:

• Mining & Quarrying: Crusher liners, loader buckets, dumper truck bodies.
• Construction: Concrete mixers, bulldozer blades, road paving equipment.
• Material Handling: Coal conveyors, hoppers, chutes, and silos.
• Energy Industry: Power plant coal pulverizers, high-temperature abrasion environments.

Using NM500 wear plate allows thinner plate design while maintaining durability, which can help improve payload efficiency and reduce overall equipment weight.

For practical examples and selection guidance, see NM400 / NM450 / NM500 wear plates for mining and quarry equipment covering crushers, loaders, dump trucks, and bulk material handling systems.

Package & Shipment

• Type: Standard Seaworthy Packing
• Delivery time: 7-15 Days After We Get The Payment
• Size: Based On Orders
• Packaging Details: As Customer Requirement
• Availability: Large inventory ready for global export

As a reliable NM-series wear plates exporter from China, CJM provides stable supply, export documentation support, and OEM processing services to meet international project requirements.

Why Choose CJM as Your NM400/NM500 Steel Plate Supplier?

CJM supplies NM400, NM450, and NM500 wear plates for global customers with consistent quality control and reliable delivery. Our products are shipped to over 40 countries with certifications such as ISO 9001, SGS, and BV.

• Competitive Pricing: Competitive wear plate pricing based on stable stock, optimized sourcing, and flexible order quantities.
• Certified Quality: ISO 9001, SGS certified with full mill test certificates.
• Reliable Delivery: Fast, reliable delivery worldwide, with customization options to meet your project requirements.
• Global Reach: Exported to 40+ countries across Asia, Europe, Middle East, Africa, and Americas.
• Wide Range of Stock: We have a large inventory for immediate shipment.
• Customized Service: Cutting, bending, welding services tailored to project needs.

FAQs About NM400/NM500 Steel Plates

• Q1: What is NM400 wear plate mainly used for?
  A: NM400 wear plate is commonly used in mining equipment, construction machinery, and material handling systems where stable abrasion resistance and good fabrication performance are required.
• Q2: Is NM400 wear plate suitable for cutting and welding?
  A: Yes. NM400 wear plate can be cut, welded, and formed using proper procedures, making it suitable for fabricated wear parts such as buckets, liners, and chutes.
• Q3: What thickness range is available for NM400 wear plate?
  A: NM400 wear plates are commonly supplied in thicknesses from 2 mm to 100 mm, with standard sizes available from stock and cut-to-size options upon request.
• Q4: What is the difference between NM400 and NM500 wear plates?
  A: NM500 wear plate offers higher hardness and abrasion resistance than NM400, making it suitable for more severe wear conditions, while NM400 is easier to process and widely used for general wear parts.
• Q5: Are NM500 wear plates suitable for high-impact applications?
  A: Yes. NM500 combines high hardness with controlled toughness, allowing it to perform under both abrasion and moderate impact conditions when properly applied.
• Q6: How does CJM ensure competitive wear plate price?
  A: By maintaining large stock and direct supplier channels, we provide cost-effective abrasion resistant steel plates without sacrificing quality.
