Inconel 625 Plate
- OriginChina
- Delivery Time≥7 days
- DemandCustomizable
- StandardASTM, AISI, JIS, GB, DIN, EN
- MOQ 1 Ton
Product Description
Stock Display
Inspection and Packaging
Inconel 625 Plate Description
Inconel 625 is a high-performance nickel-chromium alloy that is known for its exceptional resistance to oxidation, corrosion, and high-temperature environments. It contains approximately 58% nickel, 20-23% chromium, and 8-10% molybdenum, along with small amounts of iron, aluminum, and titanium. Inconel 625 is ideal for harsh, high-temperature, and corrosive environments, making it a preferred choice in critical applications where durability and resistance to corrosion are essential.
Product Parameters
| Product Name | Inconel 625 Plate |
| Thickness | 0.3mm-200mm |
| Length | 2000mm, 2438mm, 3000mm, 5800mm, 6000mm, 12000mm, etc. |
| Width | 40mm-600mm, 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc. |
| Standard | ASTM, AISI, JIS, GB, DIN, EN, etc. |
| Surface | BA, 2B, NO.1, NO.4, 4K, HL, 8K, etc. |
| Certificate | ISO, SGS, BV |
| Production Technology | Hot Rolling, Cold Rolling |
Chemical Composition
| C | Si | S | Cr | Mn | Fe | Ni | Mo |
| 0.10 max | 0.5 max | 0.015 max | 20.0 – 23.0 | 0.50 max | 5.0 max | 58.0-63.0 min | 8.0-10.0 |
Mechanical Properties
| Tensile Strength (ksi) | 0.2% Yield Strength (ksi) | Elongation% in 2 inches |
| 116,000 | 50,800 | 35 |
Physical Performance
| Units | Temperature in°C | |
| Density | 8.44 g/cm³ | Room |
| Specific Heat | 0.106 Kcal/kg.C | 22° |
| Melting Range | 1300-1400°C | – |
| Modulus of Elasticity | 207 KN/mm² | 22° |
| Electrical Resistivity | 0.75 µΩ.cm | 20° |
| Coefficient of Expansion | 13.4 x 10⁻⁶/ °C | 20 – 100° |
| Thermal Conductivity | 11.30 w/m-° K | 100° |
Scope of Application
Inconel 625 is a nickel-based alloy known for its excellent corrosion resistance, high-temperature strength, and good weldability. It is widely used in applications requiring high strength and resistance to extreme environments.
