A Chromium-Based Solution for Safe, Printable, and Long-Lasting Packaging

Product Overview‌

Tin-Free Steel (TFS), also known as Electrolytic Chromium-Coated Steel (ECCS), is widely used in corrosion-resistant packaging where tin coating is not required. CJM supplies TFS with uniform chromium and chromium oxide layers that offer excellent adhesion, paintability, and resistance to sulfur-based compounds — making it ideal for food lids, beverage crowns, paint cans, and chemical containers.

Compared to tinplate, tin-free steel has distinct advantages in certain packaging applications. It resists sulfur-induced corrosion, offers better lacquer adhesion, and provides excellent surface finish for printing and coating. These features make it suitable for packaging products with longer shelf-life, acidic or sulfur-rich content, or decorative branding.

Key Benefits:

• Chromium coating with excellent corrosion resistance
• Ideal for external or internal lacquering
• Superior printing surface for decorative packaging
• High formability for can ends, closures, and lids
• No metal migration or discoloration in food contact
• Cost-effective alternative to traditional tinplate

CJM supplies TFS coils and sheets that meet JIS G3315 and ASTM A657 standards.

Product Dimensions

Item	Specification
Thickness	0.14 mm – 0.30 mm
Width	600 mm – 1000 mm
Chromium Coating (Cr/CrOx)	50 – 130 mg/m² (total)
Base Steel Grades	MR, SPCC, Temper T2 – T4, DR7 – DR9
Surface Finish	Bright / Matte / Silver
Coil Inner Diameter	508 mm / 610 mm
Surface Treatment Options	Lacquered, Oiled, Passivated
Standards	JIS G3315, ASTM A657, ISO 11949

Mechanical Properties

Grade	Yield Strength (MPa)	Tensile Strength (MPa)	Elongation (%)
T2	≥ 245	270–350	≥ 30
T3	≥ 275	300–370	≥ 28
T4	≥ 305	340–410	≥ 26
DR8	≥ 370	420–510	≥ 2.5
DR9	≥ 410	470–560	≥ 1.5

Applications

Tin-Free Steel is commonly used in packaging that requires both mechanical strength and corrosion resistance without tin contamination. Typical applications include:

• Cosmetic and medical packaging
• Food and beverage can ends (pull-tab lids, EOE ends)
• Paint and coating cans
• Crown caps and closures
• Aerosol domes and bottoms
• Battery cases and industrial containers

Especially suitable for acidic foods, beverages with sulfur content, and external decorative coatings.

Quality Assurance & Testing‌

• In-House Lab Testing‌: Spectrometer analysis for chemical composition, hardness testing (Rockwell B), and surface roughness checks.
• Dimensional Accuracy‌: Laser micrometers for thickness/width verification.
• Defect Detection‌: Automated eddy current scanning for surface flaws.
• Performance Tests‌: Salt spray testing (up to 500 hours) for corrosion resistance.

Production Process Flow‌

Factory & Equipment‌

Packaging & Logistics‌

• Standard Export Packaging‌: Waterproof paper + steel straps + wooden pallets.
• Flexible Options‌: OEM packaging or bulk shipments.
• Global Logistics‌: FOB, CIF, or door-to-door delivery with real-time tracking.

Contact Us‌

Ready to order or need a quote? Email or call us for more information.

Q: What is your company’s main products/services?

A: We are a professional manufacturer for Carbon Steel, Alloy Steel and Profile products. We have the experience of steel business for more than 10 years and our products are exported to Mid East,South America,Southeast Asia,Africa,South and East Asia etc.

Q: Can I go to your factory for a visit?

A: Of course, we welcome customers from all over the world to visit our factory.

Q: What are your terms of payment?

A: 30% T/T deposite and 70% balance before shipment.

Q: What is your delivery time?

A: For stocks,we could transport the goods to loading port within 7 days after we received the deposit; For production,it usually takes about 15-30 days after receiving the deposit.

Q: Do you provide samples? Are they free or paid?

A: Samples are available for free,but the courier freight will be covered by customer account.

Q: Do you accept the third party inspection?

A:Yes, we fully accept ‌third-party inspections.

Q: Why should I buy from you not from other suppliers?

A: Integrating the superior resources of China’s steel industry, we provide customers with high-quality steel products at preferential prices, and can ensure that the goods are delivered to customers in a timely manner.

Q:How can you guarantee quality?

A: Always a pre-production sample before mass production;Always 100% inspected before shipment
