S355JR C Channel is available from CJM Steel in commonly requested channel sizes for construction, structural fabrication and industrial projects. Supplied to EN 10025-2, the channel can be ordered in standard or customized sizes, lengths and quantities, with export packing and quality documentation available for international B2B orders.
We supply S355JR C Channel for distributors, fabricators and project procurement, with specifications arranged according to customer requirements. Send us your required size, length, quantity and destination for a quotation.
S355JR C Channel Specifications
S355JR C Channel is supplied as a hot rolled structural steel section according to EN 10025-2 and applicable dimensional requirements.
Item
Specification
Standard
EN 10025-2
Grade
S355JR
Product
Hot Rolled C Channel
Common Channel Size
Approx. 50–300 mm
Thickness
Approx. 4–20 mm
Length
6 m, 12 m or customized
Delivery Condition
As Rolled
Surface
Hot Rolled / Black
Processing
Cutting available if required
Custom Sizes
Available
The above ranges cover commonly traded S355JR C Channel specifications. Other sizes, thicknesses and lengths can be supplied or customized according to project requirements.
S355JR C Channel Chemical Composition
The chemical composition of S355JR C Channel is specified according to EN 10025-2. Typical maximum values include:
Element
S355JR
C
0.24%
Si
0.55%
Mn
1.60%
P
0.040%
S
0.040%
N
0.012%
The applicable chemical composition requirements depend on the ordered product and thickness. The final values are confirmed by the material certificate.
S355JR C Channel Mechanical Properties
The mechanical properties of S355JR C Channel vary according to the product thickness under EN 10025-2.
Property
S355JR
Yield Strength
≥ 355 MPa*
Tensile Strength
470–630 MPa*
Elongation
≥ 22%*
Impact Energy
≥ 27 J at +20°C
* Mechanical requirements vary according to product thickness. For example, the minimum yield strength is 355 MPa for thicknesses up to 16 mm, 345 MPa for 16–40 mm, and decreases progressively with greater thickness.
S355JR C Channel Applications
S355JR C Channel is commonly used for:
Building structures and structural frames
Heavy-duty support structures
Industrial buildings and workshops
Machinery and equipment frames
Steel fabrication
Construction projects
General engineering structures
Its higher-strength structural properties make S355JR suitable for applications where structural load requirements are greater than those typically served by lower-strength structural steel.
S355JR C Channel Supply & Processing
Channel Sizes: Various standard specifications available
Length: Standard and customized lengths
Processing: Cutting and other processing available as required
MOQ: No fixed MOQ for available stock; other quantities are negotiable
Quality Documents: MTC and other documents available according to order requirements
Inspection: Third-party inspection available if required
For project orders, specifications can be confirmed based on customer drawings, material lists or purchasing requirements.
S355JR C Channel Packaging & Transportation
S355JR C Channels are securely bundled for handling, loading and transportation. Export seaworthy packing can be arranged according to order quantity, channel length and destination.
Transportation arrangements can be coordinated for container or bulk shipment according to the order requirements.
S355JR C Channel Supplier & Exporter
CJM Steel supplies S355JR C Channel for construction, structural fabrication, industrial structures and general engineering applications. Standard specifications and customized supply options are available for different B2B purchasing requirements.
Send us your required channel size, thickness, length, quantity and destination for an S355JR C Channel quotation.
